1060 1100 3003 5052 5083 5052 5059 6061 7075 T6 Aluminum Alloy Sheet 0.6mm 0.8mm 1.0mm
| Minimum Order Quantity | 1Ton |
|---|---|
| Price | USD 2200-3000 Ton |
| Packaging Details | Wooden frame,as your request |
| Delivery Time | 15-20 Days |
| Payment Terms | T/T, L/C, D/A, D/P, Western Union |
| Supply Ability | 1000 Ton Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Grade | 1060 1100 3003 5052 5083 5052 5059 6061 7075 | Surface | Mirror,Customized |
|---|---|---|---|
| Alloy | Is | Thickness | 0.6mm,0.8mm,Customized |
| Tolerance | 1% | Material | Aluminum |
| Alloy Elements | Al--Cu/Al--Mn/Al--Si/Al--Mg/Al--Zn--M | Processing Service | Bending, Welding, Decoiling, Punching, Cutting |
| Edges | Mill Edge, Slit Edge | Shape | Flat |
| Date Of Shipment | 10-15 Days After The Deposit | Type | Aluminum Sheet |
| Characteristic | Sustainable | Length | 1-8m Or Coil |
| Transport Package | Standard Sea Export Packing | Specification | 4X8FT/5X10FT/Customize |
| Trademark | BY | Origin | China |
| HS Code | 7606910000 | Supply Ability | 1000ton/Month |
| Color | Silver | Application | Transportation Tools, Door & Window, Glass Wall, Heat Sink, Decorations |
| Certification | ISO9001, ASTM, GB, EN, ASTMB | Technique | Hot Rolling |
| Temper | T3 - T8 | Samples | US$ 10/kg 1 Kg(Min.Order) | Request Sample |
| Highlight | 1100 Aluminum Alloy Sheet 0.6mm,6061 Aluminum Alloy Sheet 0.8mm,5052 Aluminum Alloy Sheet 1mm |
||
Product Description
1060 1100 3003 5052 5083 5052 5059 6061 7075 T6 Aluminum Alloy Sheet 0.6mm 0.8mm 1.0mm
Characteristics and advantages of aluminum plate:
1. Lightweight, with good rigidity and high strength. The 3.0mm thick aluminum plate has a reverse weight of 8kg per square meter and a tensile strength of 100-280n/mm2
2. Good weather resistance and corrosion resistance. PVDF fluorocarbon paint based on kynar-500 and hylur500 can last for 25 years without color fading.
3. Good craftsmanship. By adopting the process of processing before painting, aluminum plates can be processed into various complex geometric shapes such as flat, curved, and spherical bathroom partition surfaces.
4. Uniform coating and diverse colors. Advanced electrostatic spraying technology ensures uniform and consistent adhesion between paint and aluminum plates, with diverse colors and ample selection space.
5. Not easy to stain, easy to clean and maintain. The non adhesiveness of fluorine coating film makes it difficult for pollutants to adhere to the surface, and it has better cleaning properties.
6. Installation and construction are convenient and fast. Aluminum plates are formed in the factory and do not need to be cut on the construction site. They can be fixed on the skeleton.
|
Product name
|
Embossed Aluminium Sheet Planchas Aluminio Diamantado 1060 Anti Slip Aluminum plate |
|
Grade
|
Pure Aluminum: 1A99,1A97,1A95,1A93,1A90,1A80,1A80A,1070,1070A,1370,A1060,1050,1050A,1A50,
1350,1145,1350,1A30,AA60,1200,1235,A1100 |
|
2 Series: 2A01,2A02,2A04,2A06,2A10,2A11,2B11,2A12,2A13,2A14,2A16,2B16,2A17,2A20,2A21,2A25,2A49,2A50
,2A70,2A80,2A90,2004,2011,2014,2014A,2214,2017,2017A,2177,2218,2618,2219,2024,2124 |
|
|
3 Series: 3A21, 3003, 3103, 3004, 3005, 3105
|
|
|
4 Series: 4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043A,4047, 4047A
|
|
|
5 Series: 5A01, 5A02, 5A03, 5A05, 5A06, 5B06, 5A12, 5A30, 5A33, 5A41, 5A42, 5A66,5005,5019, 5050, 5154A,
5754, 5056, 5356, 5456,5082, 5182, 5086 |
|
|
6 Series: 6A02, 6B02, 6A51, 6101, 6101A, 6005, 6006A, 6351, 6060, 6061, 6063, 6063A, 6070, 6181, 6082
|
|
|
7 Series: 7A01, 7A03, 7A04, 7A05, 7A09, 7A10, 7A15, 7A19, 7A31, 7A33, 7A52, 7003, 7005, 7020, 7022, 7050,
7075, 7475, 8A06, 8011,8090 |
|
|
Thickness
|
0.2-80mm; Customized according to customer requirements
|
|
Width
|
1000mm, 1219mm, 1240mm, 1500mm, 1800mm, 2000mm
|
|
Length
|
2000mm, 2438mm, 2500mm, 3000mm, 6000mm or as required
|
|
Application
|
Rail transit, aerospace, machinery and equipment, petrochemical, construction, automotive aluminum, shipbuilding
|
|
Lead Time
|
Normally 7-15 working days after the receipt of 30% deposit, according to the quantity
|
|
Packing
|
Standard Sea Worthy Package or according to customer's requirements
|
Aluminum has excellent oxidation and corrosion resistance, which means it can maintain stable performance in various harsh environments.
Due to its ability to prevent oxidation and corrosion in the long term, aluminum is widely used in the construction components and fuel tanks
of transportation industries such as ships, automobiles, and railways.
of transportation industries such as ships, automobiles, and railways.
If you need Aluminum Sheet such as 3003 Sheet, 5052 Sheet and 6061 Sheet, we've got you covered,we can provide qualified products to you.
In addition,we have various series of Aluminum Sheet from 1050-8011.
Chemical component (%)
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other | Al | |
| Single | Total | ||||||||||
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | _ | 0.05 | 0.03 | 0.03 | _ | ≥99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | _ | 0.05 | 0.03 | 0.03 | _ | ≥99.6 |
| 1100 | Si+Fe:0.95 | 0.05~0.40 | 0.05 | _ | _ | 0.1 | _ | 0.05 | 0.15 | ≥99 | |
| 1200 | Si+Fe:1.00 | 0.05 | 0.05 | _ | 0.1 | 0.05 | 0.05 | 0.15 | ≥99 | ||
| 3003 | 0.6 | 0.7 | 0.05~0.20 | 1.0~1.5 | _ | _ | 0.1 | _ | 0.05 | 0.15 | Remainder |
| 3105 | 0.6 | 0.7 | 0.3 | 0.30~0.8 | 0.20~0.8 | 0.2 | 0.4 | 0.1 | 0.05 | 0.15 | Remainder |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50~1.1 | 0.1 | 0.25 | _ | 0.05 | 0.15 | Remainder |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2~2.8 | 0.15~0.35 | 0.1 | _ | 0.05 | 0.15 | Remainder |
| 5083 | 0.4 | 0.4 | 0.1 | 0.40~1.0 | 4.0~4.9 | 0.05~0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Remainder |
| 5086 | 0.4 | 0.5 | 0.1 | 0.20~0.7 | 3.5~4.5 | 0.05~0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Remainder |
| 6061 | 0.4~0.8 | 0.7 | 0.15~0.40 | 0.15 | 0.80~1.20 | 0.04~0.35 | 0.25 | 0.15 | 0.05 | 0.15 | Remainder |
| 6063 | 0.2~0.6 | 0.35 | 0.1 | 0.1 | 0.45~0.90 | 0.1 | 0.1 | 0.1 | 0.05 | 0.15 | Remainder |
| 6082 | 0.7~1.3 | 0.5 | 0.1 | 0.4~1.0 | 0.6~1.2 | 0.25 | 0.2 | 0.1 | 0.05 | 0.15 | Remainder |
| 8011 | 0.5~0.9 | 0.6~1.0 | 0.1 | 0.2 | 0.05 | 0.05 | 0.1 | 0.08 | 0.05 | 0.15 | Remainder |
1.Chemical equipment,lighting appliance,reflection board,heat sink;
2.Machinery parts,such as traffic and construction structure;
3.Chemical products produciont and storage device;
4 Ships,as well as automobile components,pressure container refrigeration device;
5. Building materail,irrigation pipe for vehicle and bench,such as furniture,elevator ;
6.High stress structure,mould processing,mechanical equipment;
7.Bulding materails,construction baffle,sheet processing parts,
Bangying (Suzhou) Technology Co., Ltd. is located in Suzhou & Wuxi , the Metal/Steel Base of Yangtze River Delta Economic Circle. The company is a comprehensive metal enterprise, specializing in the materials of Steel, Copper & Aluminium, and the related Products. We enjoy a good renown in the steel markets. We have the first-class processing equipment, modern physical and chemical testing centers and the machines of "Cutting, Surface Grinding, Forming, Welding, Precision Sheet Metal" and the other supplementary equipment. We have been providing customers with safe, economical and reliable products and ODM/OEM services for more than 15 years.
We have always been adhering to the business philosophy of "integrity management, no deceit", providing clients with the high-quality at the most competitive prices, and achieving a win-win relationship of lasting cooperation. We sincerely welcome all customers and friends worldwide to inquire us without hesitation,and work together for the mutual-benefits.
.
We have always been adhering to the business philosophy of "integrity management, no deceit", providing clients with the high-quality at the most competitive prices, and achieving a win-win relationship of lasting cooperation. We sincerely welcome all customers and friends worldwide to inquire us without hesitation,and work together for the mutual-benefits.
.
Q1: What's your terms of payment?A: 30%T/T as the upfront deposit, 70% before delivery, We will show you the photos and package before you pay the balance.
Q2: What's the terms of delivery?
A: EXW, FOB, CFR, CIF
Q3: What's the terms of packing?
A: Generally,we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.
Q4: What's your delivery time?
A: For stocks, we could transport the goods to loading port within 7 work days after we received the deposit.For productionperiod, it usually takes about 15 days to 30 days after we received the deposit.
Q5: Could you produce according to the samples?
A: Yes, we can customer-made by your samples or technique drawings, we can build the mold and fixtures.
Q6: Could youprovide the compliment samples?
A: Yes, we could provide the free samples on condition that it is available in stocks, however,the transportation fee is borne by buyer.
Q7: How could you guarantee your products quality?
A: Each piece of products is manufactured by certified workshops, inspected by us piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q8:What are the advantages of your company?
A:(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.
